Hispeedido DMG Q5 RIPS XL Laminated LCD Kit with OSD Menu for Game Boy Classic

Name: Hispeedido DMG Q5 RIPS XL Laminated LCD Kit with OSD Menu for Game Boy Classic
Brand: Hispeedido
SKU: DMG-IPS-Q5-LAM
Price: 69 EUR
Availability: InStock

Category: Displays

€69.00

Incl. VAT , excl. Shipping Cost

SKU	DMG-IPS-Q5-LAM
Device	Game Boy
Brand	for Nintendo
Manufacturer	Hispeedido

Add to Wish List Compare

Details

IPS Q5 RIPS XL Laminated LCD Upgrade Kit with OSD for Game Boy Classic (DMG-01) by Hispeedido

Give your classic Game Boy DMG console an upgrade with the latest Q5 RIPS Upgrade Kit from Hispeedido!

With a resolution of 720p and 16:1 pixel scaling, the screen offers a crystal clear display with no distortion. Every pixel is displayed precisely so that you can experience your games in impressive quality. The display is already pre-laminated (glass pane industrially attached), which makes installation much easier - no more dust inclusions or dirt when attaching the display glass.

Features

High-contrast image with rich colors thanks to modern IPS LCD technology
Field of view 11% larger than the original screen
Quick and easy installation thanks to pre-installed glass lens
OSD (On Screen Display) for easy operation
8 preset color modes that you can customize to your liking
Battery indicator
Various retro effects
True transparency through frame blending

Includes

1 x IPS LCD with industrially bonded glass display panel
1 x LCD board
1 x Front PCB (keypad)
1 x ribbon cable large
1 x ribbon cable small
1 x adhesive strip

Tips

The screen section of the shell must be enlarged for installation.
Attention: the underside of the screen cut-out in the shell must be thinned out to 0.7 mm for OEM shells and other shells not intended for this kit - otherwise the LCD will be destroyed! Defects caused by installation errors cannot be replaced!
The kit comes without a speaker, this must be soldered. No soldering work is required for the rest of the installation.

Instructions

Installation instructions

Pairs well with

Hints

The mod / installation requires basic technical knowledge and appropriate tools.
ATTENTION: The Display must be tested BEFORE installation! Before you install the LCD kit, you first need to test it (dry run). It is important that the LCD is tested outside the shell BEFORE installation so that damage caused by the installation can be ruled out. Likewise, no adhesives must have been applied, LCD frames used or soldering work carried out. The LCD is very fragile and can be destroyed by even slight pressure. Complaints about kits that have already been installed will unfortunately have to be rejected without exception!

Related Products

Shipping

Your order is usually dispatched the next working day after receipt of payment as an insured parcel. After dispatch, you will receive the tracking number by email, which you can use to track the current status of your delivery.

Austria

only 3,90 EUR

Insured and with tracking

Delivery time 1-2 Business days

Shipping with Austrian Post

Free shipping from 150 EUR!

Tracking

Germany

only 4,90 EUR

Insured and with tracking

Delivery time 2-3 Business days

Shipping with DHL

Free shipping from 150 EUR!

Tracking

Other EU countries

from 7,90 EUR
up to 24,90 EUR

Insured and with tracking

Delivery time 4-10 Business days

Shipping with Regional Partners

Free shipping from 250 EUR!

Belgium - Netherlands - Bulgaria - Denmark - Estonia - Finland - France - Greece - Ireland - Italy - Croatia - Latvia - Lithuania - Luxembourg - Malta - Poland - Portugal - Romania - Sweden - Slovakia - Slovenia - Spain - Czech Republic - Hungary - Hungary

Details

Notes

For countries outside the EU: The recipient is responsible for customs duties and taxes incurred upon import into the respective country.
The actual delivery time depends on the shipping service provider in the respective destination country.
Orders placed with incorrect country information will be cancelled. A correction after ordering is very time consuming for tax reasons and can only be done in exceptional cases.

More Information

Game Boy Classic LCD Upgrade Kit from Hispeedido

Bring your Nintendo Game Boy Classic DMG-01 up to date with the IPS LCD Kit V5 Pro and experience retro gaming in a new dimension.

Ideal for retro modding and broken LCD repair projects, this kit gives you crisp, high-resolution graphics and improved viewing angles to enhance your gaming experience. Easy plug-and-play installation makes it perfect for anyone looking to modify and upgrade their retro gaming console. Compatible with original and aftermarket shells (modification may be required).
